1 台 7000USD
2 台 6500USD
3 台 6000USD
Raw Materials Request
| Suitable Material | Colored Steel plate, Galvanized Board, Aluminum Plate | |
| Thickness | 0.3-0.8mm | |
| Color | As you like | |
| Appearance size (About) | 5.0*0.8*1.3m | |
| Rows of rollers | 12 rows | |
| Rolling material | 45# steel,roller surfaces polishing, hard plating | |
| Diameter of shaft | 38mm | |
| Total power | 4 KW | |
| Productivity | 15-20m/min | |
| Cutter material | Cr12 Heat Treatment | |
| Electronic control system | PLC, Touch Screen, Encoding counter | |
Packing Method
Main machine is packaged with plastic film
Transportation
All machines need one 40 feet container to hold
Payment Term
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment.
Delivery Time
Within 35 days after receiving deposit.
Warranty
Two years, and we will provide technical support for wholelife of the equipment.
If some parts of machine broken within 2 year, we will give customer the spare parts for free. (include chain, bearing, roller,oil pipe, counting wheel) If more than 2 year, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is perfect. If you need, we can go to your place to assist you. But you need to provide the cost of the engineer.
We are one of the best cold roll forming machinery and equipment manufacturers and suppliers in China.
