1. Brief of our company
“The quality first, The prestige first” is the service aim of our company, we wish to customize the best machines for customers. So all stuff from our company welcome anyone who are interested in our machines come to investigate and talk about cooperation.
2. Machinery Parameters and Others Related Parameters, as follows
| Main Technical Parameters: | |
| Auto Machinery Equipment With PLC Control System | |
| 1. Manual Un-coiler | |
| Max Capacity | 5000 kgs |
| Inner diameter of coil | 400-600 mm |
| Manual with brake | |
| 2. Leveling Device | |
| Ensure the material level and straight | |
| The width can be adjusted | |
| 3. Punching Device | |
| Punching way | pre/post punching (pause to punch or Tracking) |
| Material of punching mould | Cr12 with heat treatment |
| Punching Mould | as per drawings |
| 4. Main Forming System | |
| Max Feeding Width | as per drawings |
| Product Max Effective Width | as per drawings |
| Thickness of Panel | 0.2-2.0 mm |
| Material Type | GI sheet coil or cold rolled coil or Aluminium etc. |
| Diameter of Main Shaft | 95mm |
| Rollers Station | 12 Rows |
| Roller Material | C45 steel,Heat Treatment |
| Surface of Roller | Chrome plating, Heat Treatment |
| Driving Mode | By Chain and Gear Box |
| Main Motor Power | 5.5 Kw |
| Machine Body | Electrostatic Spraying Treatment |
| Forming Speed | Min. 0-15 m/min |
| The machine base is assembled and welded by high quality steel | |
| 5. Hydraulic Cutting System | |
| Cutting Way | Pause to Cutting or Tracking (Flying) ,Non-stop |
| Oil pump station | 1 set |
| Hydraulic Oil Pump | CB-E310 |
| Hydraulic Station Power | 7.5 Kw With Cooling System |
| Blade Material | CR12 with heat treatment HRC60-62 |
| Cutting mould | as per drawings |
| Forced air cooling device available | |
| 6. Electrical System (PLC&HMI Control System) | |
| Electrical System | PLC and HMI touch Screen (Taiwan Delta) |
| Automatic Measuring Length Function Available | Yes, Rotary Encoder |
| Automatic Counting Function Available | Yes |
| Current Protection Function Available | Yes, Aviation Plugs |
| Power Supply | 380V, 50Hz, 3 Phase (as per local requirement) |
| 7. Run-Out Table | |
| Frame | 8# steel groove welded |
| roller type | |
| Quantity | 1 pc |
| (They can be modified according to customer requirements) | |
1. Low cost, light weight but high strength, short building period, and re-cycle use
2. Save material , no waste.
3. Easy operation, low maintenance cost
4. Infinite sizing(any size within machine range),help to save material
5. Optional Punch hole at any position of purlin web side and flange side
Some relative terms we can provide:
1. Minimum order quantity (MOQ): 1 piece
2. Delivery time: about 45 workdays
3. Port of loading: port of Xiamen
4. Type of payment: by T/T or by L/C
5. Export: Australia, UK, Ireland, Mexico, Brazil ,Israel ,Dubai, Russia ,India, Taiwan, Singapore,
Malaysia ,Thailand, Philippines, Myanmar ,Vietnam, South Africa, Mozambique,
Zambia, Zimbabwe, Nigeria, Egypt, Sudan, etc.
Packing Method
Main machine is packaged with plastic film
Transportation
All machines need one 20 feet container to hold
Payment Term
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment.
Delivery Time
Within 35 days after receiving deposit.
Warranty: Two years, and we will provide technical support for wholelife of the equipment. If some parts of machine broken within 2 years, we will give customer the spare parts for free. (include chain, bearing, roller, oil pipe, counting wheel) If more than 2 years, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is perfect. If you need, we can go to your place to assist you. But you need to provide the cost of the engineer.
FAQ
Q1. What’s your payment terms and delivery time?
A1: 30% as the deposit by T/T in advance, 70% as the balance payment by T/T after your inspect the machine well and before delivery. Of course your payment terms are acceptable.
After we get down payment, we will arrange production. About 30-45 days for delivery.
Q2. Do you have after-sales support?
A2: Yes, we are happy to provide advice and we also have skilled technicians available across the world.
Q3. Do you sell only standard machines?
A3: No, most of our machines are built according to customers specifications, using top brand components.
Q4. What will you do if the machine is broken?
A4: We provide 18 months free warranty and free technical support for the whole life of any machine.
If the broken parts can’t repair, we can send the new parts replace the broken parts freely, but you need pay the express cost by yourself. If it is beyond the warranty period, we can negotiate to solve the problem, and we supply the technical support for the whole life of the equipment.
Q5. Can you be responsible for transport?
A5: Yes, please tell me the destination port or address. we have rich experience in transporting.
Q6. How to visit your company?
A6: 1) Fly to Beijing airport, By high speed train From Beijing Nan to Cangzhou Xi (1 hour).
2) Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.
